Specifications
- Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%) 50W + 50W
- Output power 4 Ohm (1 kHz, T.H.D. 0.7%) 85W + 85W
- Total Harmonic Distortion 0.01% (-3dB, 8ohm, 1kHz)
- Power Amplifier Circuit Advanced HC Single Push-Pull Circuit
- Power Amp Output circuit Structure Single Push-Pull with Darlington transistor
- Pre Amplifier Circuit Variable Gain Preamplifier
- Volume Electric - Controlled by Encoder
- Bass Treble Mid Balance Control Yes / Yes / No / Yes
- Source Direct Yes
- Input Sensitivity: MM 2.5mV / 47 kohm
- Input Sensitivity: MC 200
- Signal to Noise Ratio: MM/MC 86 dB / 71 dB
- Input Sensitivity: High level 105 mV / 40kohms (Source Direct Off)
- Signal to Noise Ratio: High level 105dB
- Treble Control ± 8 dB at 10 kHz
- Bass Control ± 8 dB at 100 Hz
Features
- Advanced HC-TR single push pull circuit Yes
- Wide range amplifier Yes
- High current dynamic power supply Yes
- Power amp discrete construction Yes
- Micro processor auto off Yes
- Solid Heat Sinks Yes
- Wi-Fi / Wired LAN Yes / Yes
- Wi-Fi 2.4GHz (11b/g/n) 5GHz (11a/n/ac)
- Wi-Fi Off Mode Yes
- Bluetooth / aptX / NFC Yes / No / No
- Internet Radio Yes (TuneIn)
- Pandora Yes (NA)
- Sirius XM Internet Radio Yes (NA)
- Spotify Connect Yes
- Deezer Premium+ / Deezer HiFi Yes / No (NA / EU)
- QQ MUSIC Yes (China)
- Sound Cloud Yes
- Tidal Yes (NA / EU)
- Amazon Music Unlimited / Amazon Music HD / Prime Music Yes / Yes / Yes
- Napster Yes
- iHeartRadio Yes (NA)
- Mood Mix Yes (NA / EU)
- AWA Yes(Japan)
- Other Yes
- Airplay Yes (Airplay 2)
- DSD-Audio network streaming Yes (5.6Mhz)
- Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
- Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF Yes / Yes / Yes / Yes / No
- Gapless Playback Yes
- Remote APP: iDevice / Android Yes / Yes
- Sample Rate digital In 192 kHz / 24-bit
- USB-A: DSD / WAV / FLAC / AIFF / ALAC <=5.6 / 192 / 192 / No / 96
- Works with Amazon Alexa Yes
- Works with Google Assistant Yes
- Works with Apple AirPlay (Siri) Yes
Others
- Low Noise OELD display Yes
- Source Direct Yes
- Display: Dimmer / Off Yes / Yes
- IR Learning for TV Yes
Inputs Outputs
- Audio Inputs RC-1246
- Digital in: USB-B / optical / coaxial / USB-A 0 / 3 / 1 / 1
- Phono Input: MM / MC Yes / Yes
- Audio Outputs
- Pre-out / Main-in Subwoofer / No
- Power Amp Direct IN No
- Gold plated Cinch Yes
- Speaker A / B Yes
- Remote Control Bus in / out Yes (Remote Out)
- Headphone Out Yes
- Headphone Gain Control (low / mid / high) No
General
- Available colors: Premium Silver / Black Yes / Yes
- Metal Front Panel Aluminum
- Power Consumption in W 200W
- Standby Consumption in W 0.2W
- Auto Power Off Yes
- Detachable Power Cable Yes
- Remote Control RC-1246
- System Remote Function Yes
-
Maximum Dimensions (W x D x H)
434 x 376 x 131mm
17.1 x 14.8 x 5.2in -
Weight
8.3kg
18.3lb -
Carton Maximum Dimensions (W x D x H)
518 x 385 x 209mm
20.4 x 15.2 x 8.2in -
Carton Weight (inc. product)
10.3kg
22.7lb
