Features
- Channels 2
- Sample Rate digital In 192 kHz / 24-bit
- USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 <=11.2
- USB-B PCM sample rate 384 kHz / 32-bit
- Asynchronous mode rear USB Yes
- Bit-perfect transmission Yes
- Ground isolator for DAC Mode operation Yes
- Bluetooth / aptX / NFC Yes
- Balance / Bass / Treble / Loudness Yes /Yes /Yes / No
- Vertical installation Yes
- Low Noise OELD display Yes
- Source Direct Yes
Inputs Outputs
- Audio Inputs 1
- Digital in: USB-B / optical / coaxial / USB-A Yes / 2 /Yes / No
- Pre-out / Main-in No
- Number of terminals 2
- Headphone Out Yes
- Headphone Gain Control (low / mid / high) Yes
Specifications
- Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%) (20 Hz - 20 kHz, T.H.D. 0.07%) 25W (1kHz)
- Output power 4 Ohm (1 kHz, T.H.D. 0.7%) (1 kHz, T.H.D. 0.7%) 50 W
- Total Harmonic Distortion 0.004%
- Signal to Noise Ratio: MM/MC No / No
- Input Sensitivity: High level 70 mV
- Signal to Noise Ratio: High level 110dB
- Treble Control ± 8 dB at 12 kHz
- Bass Control ± 8 dB at 100 Hz
General
- Available colors: Premium Silver / Black Yes / No
- Power Consumption in W 35
- Standby Consumption in W 0.2
- Auto Power Off Yes
- Detachable Power Cable Yes
- Remote Control RC-1220
- Maximum Dimensions (W x D x H) in inches 7.87 x 9.45 x 3.39
- Weight in LBS 5.75
