DRA-800H

2.2 Ch. 145W Stereo Network Receiver with HEOS® Built-in

Denon stereo receiver built with Hi-Fi amplification seamlessly integrates with the latest Hi-Res audio, wireless, voice control and AV receiver technologies including five 4K Ultra HD HDMI inputs.

2.2 channels
100 watts per channel
4K Ultra HD
Voice Control
HEOS Built-in
5 HDMI inputs

Select Quality

Colour

Black PremiumSilver

DRA-800H

Details & Specifications

Features

Channels 2
Digital in: USB-B / optical / coaxial / USB-A No / 2 / 1 / 1
Sample Rate digital In 192 kHz / 24-bit
USB-A: DSD / WAV / FLAC / AIFF / ALAC <=5.6 / 192 / 192 / No / 192
DAC chip AK4458
Tuner: DAB / DAB+ / FM (RDS) Yes / Yes
Bluetooth / aptX / NFC Yes / No / No
Streaming audio from PC Yes
Wi-Fi / Wired LAN Yes / Yes
Internet Radio Yes
AirPlay 2 Yes
Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes
Amazon Prime Music* / Pandora* Yes / No
HEOS Multiroom and Streaming Yes
Voice Control - Works with Amazon Alexa Yes
Voice Control - Google Assist / Apple Siri Yes
DSD-Audio network streaming Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF Yes / Yes / Yes / Yes / No
Gapless Playback Yes
Remote APP: iDevice / Android Yes / Yes
Wide range amplifier Yes
Power amp discrete construction Yes
Balance / Bass / Treble / Loudness Yes / Yes / Yes / No

Others

Inputs/Outputs

Audio Inputs 5
Digital in: USB-B / optical / coaxial / USB-A No / 2 / 1 / 1
Phono Input: MM / MC Yes / No
Pre-out / Main-in subwoofer / Zone2
Gold plated Cinch Yes
Speaker A / B Yes
Number of terminals 4
Remote Control Bus in / out Yes / No
HEOS Link compatibility: IR / IP Yes
Headphone Out Yes

Specifications

Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%) 100 W (0.08%)
Total Harmonic Distortion 0.01%
Input Sensitivity: MM 2.5 mV / 47 kohm
Signal to Noise Ratio: MM/MC 74 dB / No
Input Sensitivity: High level 200mV / 47k ohm
Signal to Noise Ratio: High level 98dB
Treble Control ± 6 dB at 20kHz
Bass Control ± 6 dB at 20Hz

General

Available colors: Black / Premium Silver Yes / Yes
Metal Front Panel Yes
Power Consumption in W 220
Auto Power Off Yes
Detachable Power Cable Yes
Remote Control RC-1235
System Remote Function Yes
Maximum Dimensions (W x D x H) in mm 434 x 339 x 151
Weight in kg 8.6
Carton Maximum Dimensions (W x D x H) in mm 523 x 435 x 232
Carton Weight (inc. product) in kg 10.3
