CEOL N11DAB

Hi-Fi Network CD Receiver with HEOS Built-in and DAB+ Tuner

Your sound possibilities are nearly endless. Listen to your favourite CD, stream your playlists via Spotify, Amazon Music HD or Tidal, go multi-room with HEOS Built-in, using Bluetooth® or your network. Enjoy Internet Radio, DAB+ and AirPlay2.

Stereo amplifier
35W per channel (8 ohms)
Multiple format CD player
HEOS Built-in
Optical inputs
Amazon Alexa

Select Quality

Colour

Black White Gray

Black

CEOL N11DAB

Details & Specifications

Owner’s Manual

Features

High Quality Power Output 2 x 65 W
CD Compatibility: CD / CD-R/RW / WMA / MP3 Yes / Yes / Yes / Yes
Tuner: FM (RDS) / AM No / Yes
Network Audio Streaming Yes
Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes
Amazon Prime Music* / Pandora* Yes / Yes
AirPlay 2 Yes
Internet Radio tunein
HEOS Multiroom and Streaming Yes
Voice Control - Works with Amazon Alexa Yes
Voice Control - Google Assist / Apple Siri Yes
Voice Control - Microphone built-in No
Auto Power On by optical input signal Yes
TV remote learning Yes
PC Direct by rear USB-B No
Bluetooth / aptX / NFC Yes / No / No
USB-A: DSD / WAV / FLAC / AIFF / ALAC 5.6 / 192 / 192 / No / 192
Ethernet / WiFi Yes / Yes
WiFi setup: WPS / WiFi Sharing Yes / Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless formats: FLAC HD / ALAC / WAV / AIFF / DSD Yes / Yes / Yes / No / Yes
Gapless Playback Yes (FLAC, WAV, DSD)
Tone Control: Bass / Treble / Balance Yes / Yes / Yes
Low Noise OELD display 3 line
Clock Yes
Sleep Timer Yes
Programmable Timer: Once / Daily Yes / Yes

Inputs/Outputs

Analogue In/out 1 / No
Digital Optical In / Out 2 / No
Rear USB-B No
Subwoofer PreOut Yes
Main PreOut No
Speaker Terminal: push type / Screw Type Yes / No
Headphone Out Yes

Specifications

Power Output (6 ohm, 1kHz) 60 W / 4 ohms
Number of channels 2
Freq. Response (Analog In) 20 Hz - 20 kHz
Signal to Noise Ratio (audio) 86dB
Total Harmonic Distortion (audio) 0.1(1kHz/5W/ 4 ohms)
Frequency Range FM 87.5 - 108 MHz
Signal to Noise Ratio (Mono/Stereo) FM 74/70 dB
Total Harmonic Distortion (Mono/Stereo) FM 0.3 / 0.4%

General

Available colors: Black / White / Grey Yes / Yes / Yes
Remote Control RC1222
Power Consumption in W 55
Standby Consumption in W 0.4
Maximum Dimensions (W x D x H) in mm 280 x 305 x 108
Weight in kg 3.4
Carton Maximum Dimensions (W x D x H) in mm 389 x 382 x 226
Carton Weight (inc. product) in kg 4.7

Speakers

Type 2-way, reflex
Drivers 12cm bass-mid,
3.0cm dome high
Frequency range 50Hz–20kHz
Impedance (ohms) 6
Maximum Dimensions (W x D x H) in inches 153 x 200 x 233
Weight in kg 2.4
