AVR-X4700H

9.4 声道 AV 环绕立体声功放

Denon AVR-X4700H 9.2声道8K AV接收机，单声道235W，支持3D音频格式，如Dolby Atmos®、Dolby Atmos Height Virtualization技术，DTS:X®，DTS Virtual:X™，IMAX®增强技术和Auro-3D®。配备更新HDMI接口，支持8K/60Hz和4K/120Hz传输、VRR、ALLM、动态HDR、HDR10+和eARC。

9.2 channels
125 watts per channel
8K Ultra HD
3D Audio
HEOS Built-in
8 HDMI inputs

选择 Quality

Color

库存情况:

Item Unavailable

查找零售商

AVR-X4700H

Experience a feature-filled AV receiver

The latest visual and 3D audio formats via 8K HDMI with eARC support ensure incredible entertainment experiences for years to come..

AVR-X4700H

Optimized for high-impact audio experiences

AVR-X4700H

Optimized for high-impact audio experiences

Ultimate Home Theatre Experience — 8K Ready

The AVC-X4700H delivers the ultimate home theatre experience with 8K/60Hz pass-through, 4K/120Hz pass-through for gaming, and support for the latest HDMI speciﬁcations. The new AVC-X4700H lets you build the best 4K home theatre today and is 8K ready when you are.

Full 3D Audio Support

Immerse yourself in 3D audio with Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X®, DTS Virtual:XTM and |MAX® Enhanced. Set up a 5.1.4 or 7.1.2 Dolby Atmos surround system using the nine channels of amplification built-in to the AVC-X4700H.

8K HDMI Video Section with eARC Support

Enjoy your favourite movies, shows and games with the best picture quality available. The AVC-X4700H features an advanced HDMI section (8 in/3 out) with a dedicated 8K input that will support 8K/60Hz and 4K/120Hz video pass-through and upscaling.

High-Resolution audio

Enjoy superb audio fidelity with your favourite high-resolution audio tracks from your favourite sources.

Denon标志性声音

音响创新历程

一个多世纪以来，我们精心打造众多先进音响产品，打造细腻丰富的音质。传承日本悠久工艺，每件产品均由我们的“声音大师”手工调谐。

比较Denon AV接收器

此型号

AVR-X4700H

9.4 声道 AV 环绕立体声功放

9.2 channels

125 watts per channel

8K Ultra HD

AVR-X2800H

配备内置HEOS®的7.2声道150W 8K AV接收机

7.2 channels

95 watts per channel

8K Ultra HD

AVR-X4800H

9.4 声道 AV 环绕立体声功放

9.4 channels

125 watts per channel

8K Ultra HD

定制您的声音具有完整的连接和控制

Denon 产品的每个元素都经过精心打造，旨在提供令人难忘的音频体验。

AVR-X4700H

详细信息和规格

在线说明书

Multichannel Surround

DTS HD Master / DTS:X Yes / Yes
DTS Neo:X / DTS Neural:X No / Yes
DTS Virtual:X Yes
Dolby TrueHD / Dolby Atmos Yes / Yes
Dolby ProLogic Il / Dolby Surround No / Yes
Auro 3D Yes
Multichannel Stereo Yes
Max Number of Processing (Preamp) Channels 11.2
IMAX Enhanced Yes

Sound Enhancements

Discrete Power Amplifier 9
D.D.S.C. HD Digital Yes (32 bit)
Pure Direct Yes
High Grade Audio Components Yes
Clock Jitter Reducer Yes
Alpha Processing AL32 Processing Multichannel
Denon Link HD Yes
Audyssey MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
Audyssey LFC Yes
Audyssey APP Support Yes
Compressed Audio Restorer Yes

Network

HEOS Multiroom and Streaming Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
DSD Audio Streaming up to DSD5.6
FLAC HD 192/24 Yes
WAV 192/24 Yes
ALAC 192/24 Yes
Gapless playback Yes (FLAC, WAV, ALAC, DSD)
AirPlay Audio Streaming Yes
AirPlay 2 Yes
Internet Radio TuneIn
Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes
Compatible with Remote APP for Smart Phones Android / iOS
Compatible with Remote APP for Tablets Android / iOS/Amazon Kindle
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Yes

HDMI

HDMI Inputs: Back / Front 7 / 1
HDCP 2.2 support Yes
HDCP2.3 support Yes
HDMI Outputs: Main / Zone 2 / 1
HDMI max Resolution (8k / 4k) 8k/60 - 4k/120**
Video Conversion Analog -> HDMI Yes
Analog to HDMI Scaling 480i/576i up to 8K 60/50
HDMI to HDMI Scaling up to 8K 60/50
GUI Overlay on HDMI Yes
HDMI: 8K / 4K / CEC / eARC Yes / Yes / Yes / Yes
HDMI: 3D / 4K / CEC / ARC Yes / Yes / Yes / Yes
HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG Yes / Yes / Yes / Yes
Enhanced ARC Yes
HDMI: ALLM / QMS / QFT / VRR Yes / Yes / Yes / Yes
HLG / Dolby Vision Yes / Yes
4K Signal Pass-through / Scaling / GUI Overlay Yes / Yes / Yes
HDMI pass-though in standby mode Yes
Picture Adjust / Noise Reduction Yes / Yes
CEC Yes
DSD Audio Capability Yes
Audio Return Channel Yes
Auto LipSync Yes

Multi-room / CI

HEOS Multiroom integrated Yes
TV Sound grouping Yes
Multi-Room Zones 3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Preout Yes / Yes
Zone HDMI Output from HDMI Source Yes
Webbrowser User Interface Yes
Smart Remote Management Yes
IP Control / RS232 Control / Web Control / App Control Yes / Yes / Yes / Yes
Remote In / Out Yes / Yes
DC Trigger Output 2

Others

Voice Control - Works with Amazon Alexa Yes
Auto Speaker Setup by Microphone Audyssey MultEQ XT32
FL Display 2 lines
Graphic User Interface - GUI Advanced
ISF Certification Yes
GUI Languages 9
Setup Assistant Yes
Quick Select Plus / Quick Select Yes / No
Firmware Update by: Network / USB Yes / Yes
Variable Cross Over Yes
Optimized Bass Redirection Yes
Bass Sync Yes
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes

Inputs/Outputs

Composite In / Out 3 / 2
Component In / Out 2 / 1
HDMI In / Out 7+1 / 3
Multi-room Video Out: Video / HDMI Yes / Yes
Analogue In/out 5 / No
Phono (MM) In Yes
Digital In: Optical / Coaxial 2 / 2
Multi-room Out: Analog / Digital 2 / No
Multichannel Pre-Out Yes (11.2)
Subwoofer Out 2 (independent)
Speaker Terminal: Gold Plated Screw / Regular Screw No / Yes
Number of Speaker Terminals 11
Speaker A/B / Bi-amp Drive / Multi-Room Speaker assignable
Speaker A / B assignable
Bi-amp Drive assignable
Multi-Room Speaker Terminal assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / Yes / Yes
USB Audio / Made for iPod / Made for iPhone Yes / AirPlay / AirPlay
FM Tuner with RDS Yes

Specifications

Number of Power Amps 9
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 125 W
Power Output (6 ohm, 1kHz, 0.7% 2ch Drive) 165 W
Power Output (6 ohm, 1kHz, 1% 1ch Drive) 200 W

General

Available colors: Black / Premium Silver Yes / Yes
Metal Front Panel Yes
System Remote Control RC-1219
Pre-programmed / Learnable / LCD Display Yes / No / No
Power Consumption in W 710
Power Consumption No-Sound (ECO On / Off) in W 65 W / 110 W
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Network Control On Consumption in W 3.7
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches
434 x 389 x 167
(434 x 389 x 236)
【 434 x 379x 167 】
Weight in kg 13.7
